TrackedZeroTailExcavatorsEZ30:designed for con-struction site champions
Our brand new EZ30 has proven its excellent maneuverability and amazing work efficiency in various work applications thanks to the brand new LUDV hydraulic system and the stage 4 Yanmar engine. The EZ30 can be extremely competitive for large demolition jobs. The maximum hydraulic flow for the auxiliary hydraulics can reach up to 21.5 I/min and 180 bar, clearly setting it apart from its competitors. Its compact design, especially the zero tail and removable cab, are ideal for working in confined areas - restricted in height or width. Don't worry if you are always working under time pressure,our seat and overall cabin design wil provide you the best comfort during long working hours. Look no further,this is your ideal choice.
Faster and stronger performance
The machine has a Stage IV engine fitted, which is just as powerful as before, but produces fewer emissions and is kinder to the environment.
Combined with the new hydraulic system, the machine is more powerful and faster than ever before.
Zero Tail
When space is limited: Pivot safely, even in the tightest of spaces or right next to the wall - with the Zerotail Excavator without rear overhang, noproblem.
Optimum working in confined spaces, a high degree of maneuverability and time savings are guaranteed.
Canopy can be easily disassembled
The easy disassembly of the canopy allows optimal maintenance access.
On the construction site too, low passage heights can be overcome quickly by disassembling it and reassembling for safe operation.
Easy service and maintenance access
Easy service, thanks to wide-opening engine hood, allows easy access to all parts.
No disassembly of heavy parts necessary, additional easily replaceablewear parts.
Quick and unrestricted access. Hydraulic and engine oil filters, air filter,water separator and also the tank filler neck are ideally accessible. Lowservice costs.
Wacker neuson EZ30 Mini Excavator: Compact Power for Flexible Excavation Work
When I talk with customers about a compact Excavator, one question comes up again and again: how can we get enough digging performance without bringing a machine that is too large for the jobsite? This is where the Wacker Neuson EZ30 gets interesting.
From my experience supplying construction machinery to customers in different markets, the right excavator is not always the biggest excavator. On many construction sites, road projects, landscaping jobs, utility worksites, and municipal projects, operators need a machine that can move easily, work in limited areas, and still provide enough digging force for regular excavation tasks.
The EZ30 is a compact tracked excavator in Wacker Neuson's mini excavator range. According to the manufacturer's current technical information, the machine has an operating weight of about 2,860 kg, a width of 1,570 mm, a height of 2,414 mm, and a maximum digging depth of 2,737 mm. Its rated engine power is 15.2 kW at 2,500 rpm. These figures put the EZ30 into a practical size class for customers who need more working capability than a very small mini excavator but still want a compact machine.
For us at Ganglong Heavy Industry Technology (Hefei) Co., Ltd., the EZ30 is also a product that fits naturally into our broader construction machinery supply business. We work with customers looking for Excavators, loaders, mining machinery, agricultural machinery, and matching attachments. When a customer requests a Wacker Neuson machine, our job is to help with sourcing, configuration discussion, inspection, international trade arrangements, transportation, and after-sales communication according to the actual order.
I always prefer to look at a machine from the operator's point of view. Can it enter the work area? Can it dig deep enough? Is the machine easy to control? Can the operator perform daily checks without wasting time? Can the machine work with useful attachments? These practical questions often matter more than a long list of marketing words.
The Wacker Neuson EZ30 has several characteristics that make it worth considering. It uses a Yanmar three-cylinder diesel engine, a load-sensing hydraulic system, hydraulic pilot controls, two travel speeds, and a compact undercarriage. The official specifications list hydraulic system pressure at 240 bar and hydraulic flow at 70 L/min in the standard configuration information.
In simple terms, I see the EZ30 as a machine for customers who need a Compact Excavator that can handle real daily work without taking up unnecessary space.
Before discussing applications, I think it is better to start with the numbers. A machine can look impressive in photographs, but specifications tell us whether it actually fits a customer's project.
| Item | Wacker Neuson EZ30 |
|---|---|
| Operating Weight | 2,860 kg |
| Engine Manufacturer | Yanmar |
| Engine Model | 3TNV80F-SNWN1 |
| Engine Power | 15.2 kW at 2,500 rpm |
| Engine Displacement | 1,266 cm³ |
| Maximum Digging Depth | 2,737 mm |
| Machine Width | 1,570 mm |
| Machine Height | 2,414 mm |
| Hydraulic System Pressure | 240 bar |
| Hydraulic Flow | 70 L/min |
| Fuel Tank Capacity | 36 L |
| Travel Speed | 2.1 km/h / 3.8 km/h |
| Maximum Breakout Force | 22.4 kN |
| Maximum Tearout Force | 16.3 kN |
| Maximum Digging Reach | 4,624 mm |
| Tail Swing Radius | 770 mm |
Source: Wacker Neuson official EZ30 technical data.
One detail I pay attention to is the combination of machine width and digging depth. The EZ30 is 1,570 mm wide while reaching a maximum digging depth of 2,737 mm. That combination gives the operator useful reach without moving into the physical size of a larger excavator.
The machine also has two travel speed settings. The official technical data lists approximately 2.1 km/h for the first travel speed and 3.8 km/h for the second. This is useful when moving between work areas because the operator can choose a slower setting for controlled work and a faster setting for site movement.
The EZ30 also provides 22.4 kN of breakout force and 16.3 kN of tearout force according to the manufacturer's published specifications. For everyday excavation, trenching, landscaping, and utility work, these figures give a useful indication of the machine's working capability.
Another useful number is the 770 mm tail swing radius. A compact rear-end design can make a meaningful difference when the machine is working close to buildings, walls, roads, fences, or other equipment.
A mini excavator looks simple from the outside, but several systems work together every time the operator moves the bucket.
The basic working process starts with the diesel engine. The engine provides mechanical power, which is then used to drive the hydraulic system. Hydraulic oil is pressurized and sent through the control valves to different hydraulic actuators. These actuators move the boom, arm, bucket, and other functions.
The EZ30 uses a load-sensing hydraulic system with load-independent flow distribution. In practical language, the hydraulic system is designed to send hydraulic power where it is needed according to the operator's control inputs. This is important when the operator is combining movements rather than performing only one movement at a time.
For example, during trenching, an operator may need to lower the boom, move the arm, curl the bucket, and rotate the upper structure in a controlled sequence. Smooth hydraulic response makes these movements easier to manage.
The EZ30 also uses hydraulic pilot controls through the joysticks. Instead of relying on complicated mechanical controls, the operator uses the joysticks to command hydraulic functions. For an experienced operator, this provides a direct way to control digging movements. For a newer operator, good control response can also make the learning process easier.
The machine's travel system has two speeds. When the excavator is working directly in the digging area, the lower speed provides controlled movement. When the operator needs to reposition the machine on the site, the higher travel speed can reduce unnecessary movement time.
The boom can also be offset to the left and right. According to the official dimensional data, the maximum boom offset reaches 765 mm to one side and 531 mm to the other, depending on the measurement reference. This type of boom movement can be useful when digging close to obstacles because the machine does not always need to be positioned directly in front of the trench.
From a working perspective, this is one of the things I like to explain to customers. A compact excavator is not simply a smaller version of a Large Excavator. The value comes from how the size, hydraulic system, working equipment, and movement flexibility work together.
The EZ30 has a published width of 1,570 mm and a height of 2,414 mm. For many construction and landscaping jobs, keeping the machine compact is important because access can be a bigger problem than digging power.
Urban projects often involve narrow entrances, existing buildings, fences, sidewalks, utility lines, and other obstacles. A machine that is too large may spend more time being positioned than actually working.
The EZ30 gives contractors a useful middle ground: larger and more capable than an ultra-compact excavator, while still remaining relatively easy to place on smaller jobsites.
The maximum digging depth is listed at 2,737 mm. This is useful for trenching, drainage work, landscaping, foundation preparation, utility installation, and general excavation where a shallow machine may not provide enough reach.
Of course, maximum digging depth should never be treated as the same thing as normal working depth. Actual performance depends on bucket configuration, ground conditions, machine position, and the way the excavation is carried out.
The load-sensing hydraulic system is another important feature. The system is designed around hydraulic demand rather than simply pushing maximum flow all the time.
For the operator, this can mean smoother control during combined movements and more practical use of hydraulic power. When the job requires careful bucket positioning, controlled trenching, or attachment operation, hydraulic response becomes especially important.
The current Wacker Neuson technical data for the EZ30 lists a Yanmar 3TNV80F-SNWN1 engine with 1,266 cm³ displacement and 15.2 kW rated power at 2,500 rpm.
When we discuss engine configuration with a customer, we do not simply copy a specification from an old brochure. We check the destination market and actual supply configuration. Wacker Neuson itself notes that engine and equipment configurations can vary by country and delivery version, so the final quotation should always be matched with the actual machine being supplied.
The two-speed travel system is useful for daily site movement. Slow travel gives the operator better control when positioning the excavator close to a trench or obstacle. Faster travel helps when the machine needs to move between nearby work areas.
A compact excavator becomes much more useful when it can work with suitable attachments. Depending on the exact configuration and market availability, customers may consider different buckets and hydraulic attachments for digging, grading, cleaning, or other site tasks.
At Ganglong, we always recommend confirming the attachment type, hydraulic flow requirement, mounting interface, and working pressure before placing an order. This small check can prevent a surprisingly expensive problem later.
Customers often ask me whether they should choose the EZ30 or a smaller machine. I normally answer with another question: what work are you actually doing?
If the project mainly involves very light landscaping and shallow excavation, a smaller excavator may be enough. If the project involves deeper trenching, heavier digging, or longer working hours, the additional capacity of the EZ30 can make more sense.
| Model | Operating Weight | Max. Digging Depth | Width | Engine Power |
|---|---|---|---|---|
| Wacker neuson EZ17 | Approx. 1.8–2.2 t depending on configuration | Approx. 2.3–2.5 m depending on configuration | 990–1,300 mm depending on configuration | Approx. 13.8 kW |
| Wacker neuson EZ20 | Approx. 2.02 t | Approx. 2.49 m | 1,090 mm | 13.8 kW |
| Wacker Neuson EZ30 | 2.86 t | 2.737 m | 1,570 mm | 15.2 kW |
Source: Wacker Neuson official mini excavator product and technical data pages. Published specifications can vary by country and configuration.
The comparison shows something important: model selection is not just about engine power. Width, operating weight, digging depth, hydraulic capacity, transport requirements, and jobsite access all matter.
For example, the EZ20 is significantly narrower than the EZ30. That may be helpful when access is extremely restricted. On the other hand, the EZ30 offers a larger operating weight and greater published digging depth, which can be useful for customers who need more working capability.
I also recommend looking at transport before making the decision. A machine that fits the job perfectly but creates problems during transportation is not necessarily a practical purchase.
| EZ30 Working Data | Published Value | Why It Matters on Site |
|---|---|---|
| Operating Weight | 2,860 kg | Useful balance between compact size and working stability |
| Maximum Digging Depth | 2,737 mm | Supports deeper trenching and excavation tasks |
| Maximum Digging Radius | 4,624 mm | Provides useful working reach |
| Tail Swing Radius | 770 mm | Helpful when working close to obstacles |
| Breakout Force | 22.4 kN | Supports bucket penetration into soil |
| Hydraulic Flow | 70 L/min | Important for hydraulic functions and attachments |
| Travel Speed | 2.1 / 3.8 km/h | Allows slower positioning and faster site movement |
Source: Wacker Neuson official EZ30 technical data and dimensions.
For SEO purposes, people may search for this machine using terms such as Wacker Neuson EZ30 mini excavator, EZ30 excavator specifications, Wacker Neuson EZ30 digging depth, EZ30 compact excavator, and Wacker Neuson EZ30 for sale. These searches usually reflect practical purchasing questions rather than curiosity about the machine name alone.
I would consider the EZ30 for a wide range of applications where compact size and useful digging capability are both important.
Small and medium construction projects often involve foundation preparation, trenching, soil removal, drainage work, and general earthmoving. The EZ30 can fit into these tasks without bringing the footprint of a much larger excavator.
Road maintenance and utility work often require controlled excavation rather than massive production digging. Operators may need to open trenches for pipes, cables, drainage, or other infrastructure. In these situations, machine size and control are especially important.
Landscaping contractors can use compact excavators for soil removal, planting preparation, grading support, drainage, and site cleanup. The EZ30's compact format makes it suitable for many landscaping environments where larger construction machines would be inconvenient.
Municipal maintenance can involve sidewalks, drainage channels, roadside work, small utility projects, and public-area improvements. These jobs often happen around existing infrastructure, so a compact excavator can be easier to position.
On farms and rural properties, compact excavators can support drainage, pond maintenance, ditch cleaning, soil preparation, and small construction tasks. The key is matching the machine and attachment to the ground conditions and actual work requirement.
Contractors who handle different small projects may prefer equipment that can move between applications. With suitable attachments and the correct configuration, the EZ30 can support a variety of general excavation and site maintenance jobs.
Ganglong Heavy Industry Technology (Hefei) Co., Ltd. was founded in 2013. Together with Hefei Ganglong International Trade Co., Ltd., we operate across construction machinery, mining machinery, agricultural machinery, and related equipment supply.
We are not the manufacturer of Wacker Neuson equipment. Our role is to provide machinery sourcing, sales, leasing, international trade coordination, inspection, transportation arrangements, and related customer support. This distinction matters because we want customers to know exactly who is responsible for manufacturing the original machine and what our role is in the supply chain.
When a customer contacts us about a Wacker Neuson EZ30, I prefer to start with the project rather than immediately discussing price.
First, I want to understand the destination country, jobsite, expected application, required attachments, transport limitations, working conditions, and expected quantity.
Then we confirm the requested EZ30 configuration and availability. Because equipment specifications can vary by market and configuration, we check the actual machine details before finalizing the commercial offer.
Before shipment, our supply process can include appearance inspection, basic functional checks, hydraulic and electrical system checks, and confirmation of accessories and documents according to the order requirements.
We also pay attention to loose parts. Buckets, accessories, tools, documents, and spare parts should be clearly identified and packed properly. This sounds like a small thing, but anyone who has handled international machinery shipments knows that small packing mistakes can become large problems at the destination.
For international transportation, complete machines are generally arranged for sea shipment when suitable. Smaller parts and accessories may be sent by air or express depending on size, weight, urgency, and destination.
Machines are protected and secured according to shipping requirements. Loose accessories can be packed separately in suitable cartons or wooden cases. The final transportation and packing method is confirmed according to the destination, shipping route, machine configuration, and customer requirements.
Payment terms are normally discussed and confirmed between buyer and seller. T/T arrangements, such as a deposit followed by the balance before shipment, may be used depending on the order. We confirm the actual terms before the order is executed rather than presenting one payment method as a universal rule.
The EZ30 is a compact tracked excavator in Wacker Neuson's mini excavator range. It is designed for applications where operators need useful excavation performance while keeping the machine relatively compact.
The official Wacker Neuson technical data currently lists an operating weight of approximately 2,860 kg for the EZ30 configuration shown. Actual operating weight can vary depending on equipment and configuration.
The manufacturer's published technical data lists a maximum digging depth of 2,737 mm. Actual working depth depends on the configuration, bucket, ground conditions, and machine position.
The current technical data lists a Yanmar 3TNV80F-SNWN1 three-cylinder diesel engine with 1,266 cm³ displacement and 15.2 kW rated power at 2,500 rpm.
The published machine width is 1,570 mm. The same official dimensional information lists a 300 mm track width. Buyers should confirm the exact transport configuration before shipment.
Yes, compact excavators can be configured for different attachment applications. The exact attachment and hydraulic requirements should be checked before ordering because hydraulic flow, pressure, mounting interface, and auxiliary hydraulic configuration all need to match.
The machine can be considered for construction, road work, utility excavation, landscaping, municipal projects, agriculture, property maintenance, and general earthmoving. The correct application depends on site conditions and attachment selection.
There is no single delivery period that applies to every EZ30 order. Production or preparation time depends on machine availability, selected configuration, order quantity, destination, and other requirements. We confirm the expected delivery schedule before order execution.
According to the order requirements, we can arrange checks covering machine appearance, main functions, hydraulic and electrical systems, operating condition, accessories, and documents before shipment.
Complete excavators are generally transported by sea for international orders when suitable. Spare parts and smaller accessories may be shipped by air or express depending on their size, weight, destination, and urgency.
The machine is protected and securely fixed according to the transportation requirements. Loose accessories and spare parts can be packed separately in cartons or wooden cases. The final packing method is confirmed according to the shipping route and customer requirements.
This is one of the most important questions. Wacker Neuson states that its product range and equipment can vary depending on country, configuration, and optional equipment. Engine specifications and other details may therefore differ between markets. We recommend confirming the exact model, specifications, attachments, documents, and delivery configuration before payment and shipment.
When I look at the Wacker Neuson EZ30, I do not see it simply as another compact excavator. I see it as a practical machine for contractors who need a balance between access, digging capability, transport, and everyday operating flexibility.
Its published 2,860 kg operating weight, 15.2 kW engine power, 2,737 mm maximum digging depth, 1,570 mm width, 240 bar hydraulic pressure, two travel speeds, and 770 mm tail swing radius give customers useful numbers to work with when planning a project.
The machine can fit applications ranging from construction and utility excavation to landscaping, municipal work, agriculture, road maintenance, and general earthmoving. But the right choice always depends on the actual job. Soil conditions, digging depth, access width, attachment requirements, transportation, working hours, and local regulations all deserve attention before an order is placed.
At Ganglong Heavy Industry Technology, we focus on making that purchasing process clearer. We can discuss the application, check the requested configuration, coordinate sourcing, arrange inspection, prepare international trade documents, and organize transportation according to the order.
We also believe that a machinery supplier should be clear about what it does. Wacker Neuson is the equipment brand and manufacturer. Our role is to help customers source and arrange the equipment as part of our international machinery supply business.
If you are looking for a Wacker Neuson EZ30 mini excavator, an EZ30 compact excavator, or detailed information about Wacker Neuson EZ30 specifications, the best starting point is to match the machine with your actual project. Once we know the working conditions, destination, attachment requirements, and quantity, we can work through the supply details step by step.
